MOD Reverb Tank – StewMac

MOD Reverb Tank

The MOD® Reverb Tanks are high quality upgrade units. Some of the major differences between the MOD®s and other reverb tanks are that the Transducers are wired directly to their respective RCA jacks as opposed to current production tanks where Transducers are connected by a detachable plug to their respective RCA jacks. This makes the tanks less receptive to any outside interference. The original Hammond Accutronics tanks from the 1960s were also wired directly to their respective RCA jacks. In addition very close attention has been paid to the spacing and size of the lamination of the Transducers resulting in a more vintage like tone.

• #50820 – Replacement Reverb Tank for 4AB3C1B
• Solid, Sturdy Construction
• Long (16 ¾”) 2 Spring Unit , Long Decay (2.75-4.0 seconds)
• Input Impedance 8 Ohms, Output Impedance 2250 Ohms
• Input Insulated/Output Grounded
• Horizontal,Open Side Down Mounting Plane

Used in Fender™amps with tube reverb from 1963-1990 such as the Princeton Reverb , Vibrolux Reverb , Deluxe Reverb , Super Reverb , Pro Reverb , Twin Reverb , Quad Reverb , Super Six Reverb, Vibrosonic Reverb. This also includes all reissue equivalents.

Other compatible amps include: Fender™ ’63 Reissue Reverb Unit, Fender™ Concert II , Mesa Boogie™ MK2C plus other models, LAB™ Series L5, L7, L9, Koch™ Powertone I , Ampeg™VT-40 and Super Rocket SR212 , B-52™ AT-100.

• #50821 – Replacement Reverb Tank for 4EB3C1B
• Solid, Sturdy Construction
• Long (16 ¾”) 2 Spring Unit , Long Decay (2.75 – 4.0 seconds)
• Input Impedance 600 Ohms, Output Impedance 2250 Ohms
• Input Insulated/Output Grounded
• Horizontal, Open Side Down Mounting Plane

Compatible Amps Include: Fender® Hot Rod Deville, Hot Rod Deluxe, Blues Deluxe (reissue only), Blues Deville (reissue only). Replaces Fender® Part Number 0050394000. Also, fits Traynor™ YCV50 as well as some Music Man™ and Peavey™ models. Suitable upgrade/ replacement for the Vox™ AC30CC series amp.

The MOD® Reverb Tanks are high quality upgrade units. Some of the major differences between the MOD®s and other reverb tanks are that the Transducers are wired directly to their respective RCA jacks as opposed to current production tanks where Transducers are connected by a detachable plug to their respective RCA jacks. This makes the tanks less receptive to any outside interference. The original Hammond Accutronics tanks from the 1960s were also wired directly to their respective RCA jacks. In addition very close attention has been paid to the spacing and size of the lamination of the Transducers resulting in a more vintage like tone.

• #50822 – Replacement Reverb Tank for 8EB2C1B
• Solid, Sturdy Construction
• Short (9-1/4″) 3 Spring Unit , Medium Decay (1.75 to 3.0 seconds)
• Input Impedance 800 Ohms, Output Impedance 2575 Ohms
• Input Insulated/Output Grounded
• Horizontal, Open Side Down Mounting Plane
• Most commonly used short tank in reverb circuitry

Compatible Amps Include: Fender® Blues Jr., Deluxe 90, Princeton 65, Stage Series, Acoustasonic Junior, Vaporizer, Ultimate Chorus, Ultra Chorus, Sidekick Keyboard 60, Sidekick Reverb 35, Super 60, Super 112, Frontman 65R, Eighty-Five, Tech 21® Trademark 30, Epiphone® Valve Junior Hot Rod, Vox® AC15CC, AC15C, Ultra 60/120, Backstage, Valveking, Plus others

The MOD® Reverb Tanks are high quality upgrade units. Some of the major differences between the MOD®s and other reverb tanks are that the Transducers are wired directly to their respective RCA jacks as opposed to current production tanks where Transducers are connected by a detachable plug to their respective RCA jacks. This makes the tanks less receptive to any outside interference. The original Hammond Accutronics tanks from the 1960s were also wired directly to their respective RCA jacks. In addition very close attention has been paid to the spacing and size of the lamination of the Transducers resulting in a more vintage like tone.

• #50823 – Replacement Reverb Tank for 8AB2A1B
• Solid, Sturdy Construction
• Short (9-1/4″) 3 Spring Unit , Medium Decay (1.75 to 3.0 seconds)
• Input Impedance 10 Ohms, Output Impedance 2575 Ohms
• Input Grounded/Output Grounded
• Horizontal, Open Side Down Mounting Plane

Compatible Amps Include: Select Fender® and Mesa Boogie® models , Reverend® Hellhound(early), Goblin, and Kingsnake , PRS® SE-20 , plus others

The MOD® Reverb Tanks are high quality upgrade units. Some of the major differences between the MOD®s and other reverb tanks are that the Transducers are wired directly to their respective RCA jacks as opposed to current production tanks where Transducers are connected by a detachable plug to their respective RCA jacks. This makes the tanks less receptive to any outside interference. The original Hammond Accutronics tanks from the 1960s were also wired directly to their respective RCA jacks. In addition very close attention has been paid to the spacing and size of the lamination of the Transducers resulting in a more vintage like tone.

• #50824 – Replacement Reverb Tank for 9EB2C1B
• Solid, Sturdy Construction
• Long (16 ¾”) 3 Spring Unit , Medium Decay (1.75 to 3.0 seconds)
• Input Impedance 800 Ohms, Output Impedance 2575 Ohms
• Input Insulated/Output Grounded
• Horizontal, Open Side Down Mounting Plane

Compatible Amps Include: Vox® AC50CPH,AC100CPH, AC30CC, Peavey® Nashville 112, Fender® Hot Rod Deluxe/Deville, Plus others

The MOD® Reverb Tanks are high quality upgrade units. Some of the major differences between the MOD®s and other reverb tanks are that the Transducers are wired directly to their respective RCA jacks as opposed to current production tanks where Transducers are connected by a detachable plug to their respective RCA jacks. This makes the tanks less receptive to any outside interference. The original Hammond Accutronics tanks from the 1960s were also wired directly to their respective RCA jacks. In addition very close attention has been paid to the spacing and size of the lamination of the Transducers resulting in a more vintage like tone.
